The stock headlight on the CRF450L / CRF450RL is pretty good, but if you ride at night or just want to be seen better on the road, then there is always room for improvement. Baja Designs new Squadron Pro/S2 Headlight Kit for the CRF450L/RL is just what you're looking for. The kit utilizes your factory wiring and bar switch giving you a true plug and play setup with Hi/Lo beam functionality! The Hi/Low functions with the S2 only as low beam, and both Squadron and S2 on High. The angle of the S2 differs by pointing the beam downward 2 degrees in order to project a pattern better suited for closer range riding, and the Squadron beam is pointing farther down the trail to create a pattern for distance. The kit includes a mounting bracket that uses factory tabs, one Squadron Pro, and one S2 Sport.

We tried to get some photos showing the difference between the Baja Designs and the stock headlight. The photos shown don't really do it justice. On low beam the Baja Designs headlight is brighter and lights up a much larger area than the stock light does, especially directly in front and to the sides of the bike. On high beam, it's almost like riding during the day! If you ride at night, this headlight is a must-have!

Fitment: 2019+ Honda CRF450L / CRF450RL

Baja Designs Features:
  • Limited Lifetime Warranty – Complete Purchase Protection (through Baja Designs)
  • uService® – Replaceable Lenses And Optics
  • ClearView® – All The Light, Right Where You Need It.
  • MoistureBlock™ – Waterproof, Rain Proof, Submersible
  • CopperDrive® – Only LED Driven At 100%
  • 5000K Daylight – Less Driver Fatigue, Natural Color

    S2 Sport LED Specifications:
  • Lumens: 1,130 Utilizing 2 LEDs
  • Wattage/Amps: 12W / .9A
  • Dimensions: 2.93" x 1.76" x 1.68"
  • Weight: 8 ounces
  • LED Life Expectancy: 49,930 Hours
  • Front Lens: Hard Coated Polycarbonate
  • Housing: Hard Anodized & Powder Coated Cast Aluminum
  • Bezel: Billet Machined Aluminum
  • Hardware & Bracket Material: Stainless Steel
  • Exceeds MIL-STD810G (Mil-Spec Testing)
  • Built-In Overvoltage Protection
  • IP69K (Waterproof up to 9ft & Pressure Washable)
  • IK10 Compliant (Mechanical Impact Testing)

    Squadron Pro LED Specifications:
  • Lumens: 4,900 Utilizing 4 Cree LEDs
  • Wattage/Amps: 40W / 2.90A
  • Dimensions: 3.07" x 2.77" x 3.07"
  • Weight: 12 ounces
  • LED Life Expectancy: 49,930 Hours
  • Front Lens: Hard Coated Polycarbonate
  • Housing: Hard Anodized & Powder Coated Cast Aluminum
  • Bezel: Billet Machined Aluminum
  • Hardware & Bracket Material: Stainless Steel
  • Exceeds MIL-STD810G (Mil-Spec Testing)
  • Built-In Overvoltage Protection
  • IP69K (Waterproof, Submersible to 9ft)
  • IK10 Compliant (Mechanical Impact Testing)




  • SRMOTO PARTNER PRODUCT - Where To Buy:
    We don't currently carry this product, but we've partnered with a few companies that do. By clicking on the links below, you will be taken to one of our trusted partner websites that each offer some of the best pricing and availability on parts for your motorcycle. If you make a purchase from them, we do receive a small portion of the sale, at no extra cost to you.

  • CRF450RL Baja Designs Squadron Pro/S2 Headlight Kit at Revzilla













  • CRF450L CRF450RL Baja Designs Squadron Pro/S2 Headlight Kit
    CRF450L-490050
